Painted Hollow Sections
Painted Hollow Section – SHS & RHS Steel Profiles, Sizes, Coatings & Export from Turkey
Painted hollow sections are structural steel tubes with a protective coating applied on the surface to improve appearance and corrosion resistance. HL Metal supplies a wide range of painted steel hollow sections in both painted SHS (painted square hollow section) and painted RHS (painted rectangular hollow section) forms, tailored for construction projects, industrial fabrication and architectural steelwork.
Our product range covers pre-painted hollow sections, pre-painted steel box sections, painted box sections, and coated hollow sections for steel structures where ready-to-use painted surfaces are required. By combining structural steel grades (S235, S275, S355 and EN 10219 hollow section grades) with high-performance coatings, HL Metal offers an efficient solution for projects that demand both durability and a clean, finished look.
Whether you need painted welded hollow sections for heavy-duty fabrication, industrial painted steel tubes for machinery and platforms or powder-coated hollow sections for architectural applications, HL Metal can provide custom size painted hollow sections with competitive lead times and flexible packing options.
On this page, you will find information about our painted hollow section dimensions, detailed weight chart, coating options, standards, typical applications and export capabilities, including painted hollow section export from Turkey to Europe, the Middle East and global markets.
What Is a Painted Hollow Section?
A painted hollow section is a steel hollow section painted with an industrial coating system to provide corrosion protection and a finished surface. The base tube is typically a square hollow section (SHS) or rectangular hollow section (RHS), produced according to EN 10219 or EN 10210 and then coated with primer, topcoat or powder to create a painted steel hollow section.
In international markets, these products are also described as painted structural hollow sections, pre-painted structural steel tubing, painted steel box profiles or coated box sections. For projects with aggressive environments, HL Metal can provide anticorrosive painted hollow sections using zinc-rich primers and high-build topcoats.
Because painting is carried out under controlled workshop conditions, the final painted box section arrives at site ready for installation, reducing on-site painting works and improving quality. This is particularly beneficial for painted hollow section for construction projects where time and labour are critical factors.
For unpainted alternatives, you can also visit our dedicated Square Hollow Sections (SHS) page and Rectangular Hollow Sections (RHS) page , where you will find detailed size and weight charts.
Painted Hollow Section Sizes, Dimensions and Weight Chart
HL Metal supplies a broad range of painted square hollow sections and painted rectangular hollow sections from small decorative sizes up to large structural members. The following table presents the detailed painted hollow section weight chart, including 1-metre weights and corresponding 6-metre painted steel box profile weights.
Note: Values are theoretical and based on bare steel geometry; paint weight is normally neglected in structural calculations. Minor deviations may occur due to production tolerances.
| Painted Hollow Section Sizes | Painted Hollow Section Weights 1 M / KG | Painted Steel Box Profile Weights 6 M / KG |
|---|---|---|
| 10x20x1,20 mm | 0,52 Kg | 3,11 Kg |
| 10x20x1,50 mm | 0,70 Kg | 4,21 Kg |
| 10x30x1,20 mm | 0,71 Kg | 4,24 Kg |
| 10x30x1,50 mm | 0,94 Kg | 5,61 Kg |
| 10x30x2,50 mm | 1,37 Kg | 8,22 Kg |
| 15x15x1,50 mm | 0,70 Kg | 4,21 Kg |
| 15x25x1,20 mm | 0,71 Kg | 4,24 Kg |
| 15x25x1,50 mm | 0,94 Kg | 5,61 Kg |
| 15x25x2,00 mm | 0,97 Kg | 5,83 Kg |
| 15x25x2,50 mm | 1,37 Kg | 8,22 Kg |
| 20x20x1,20 mm | 0,71 Kg | 4,24 Kg |
| 20x20x1,50 mm | 0,94 Kg | 5,61 Kg |
| 20x20x2,00 mm | 1,25 Kg | 7,48 Kg |
| 20x20x2,50 mm | 1,58 Kg | 9,50 Kg |
| 20x30x1,20 mm | 0,90 Kg | 5,37 Kg |
| 20x30x1,50 mm | 1,17 Kg | 7,02 Kg |
| 20x30x2,00 mm | 1,56 Kg | 9,36 Kg |
| 20x30x2,50 mm | 1,76 Kg | 10,57 Kg |
| 20x30x3,00 mm | 2,07 Kg | 12,41 Kg |
| 20x40x1,20 mm | 1,08 Kg | 6,50 Kg |
| 20x40x1,50 mm | 1,64 Kg | 9,82 Kg |
| 20x40x2,00 mm | 1,76 Kg | 10,56 Kg |
| 20x40x2,50 mm | 2,15 Kg | 12,92 Kg |
| 20x40x3,00 mm | 2,81 Kg | 16,84 Kg |
| 20x40x4,00 mm | 3,26 Kg | 19,55 Kg |
| 25x25x1,20 mm | 0,90 Kg | 5,37 Kg |
| 25x25x1,50 mm | 1,17 Kg | 7,02 Kg |
| 25x25x2,50 mm | 1,97 Kg | 11,80 Kg |
| 25x25x3,00 mm | 2,07 Kg | 12,41 Kg |
| 30x30x1,20 mm | 1,08 Kg | 6,50 Kg |
| 30x30x1,50 mm | 1,40 Kg | 8,42 Kg |
| 30x30x2,50 mm | 2,34 Kg | 14,04 Kg |
| 30x30x3,00 mm | 2,81 Kg | 16,84 Kg |
| 30x30x4,00 mm | 3,26 Kg | 19,55 Kg |
| 30x40x1,20 mm | 1,27 Kg | 7,62 Kg |
| 30x40x1,50 mm | 1,64 Kg | 9,82 Kg |
| 30x40x2,00 mm | 2,18 Kg | 13,10 Kg |
| 30x40x2,50 mm | 2,55 Kg | 15,27 Kg |
| 30x40x3,00 mm | 3,28 Kg | 19,65 Kg |
| 30x50x1,20 mm | 1,46 Kg | 8,75 Kg |
| 30x50x1,50 mm | 1,87 Kg | 11,23 Kg |
| 30x50x2,50 mm | 3,12 Kg | 18,72 Kg |
| 30x50x3,00 mm | 3,74 Kg | 22,46 Kg |
| 30x50x4,00 mm | 5,62 Kg | 33,69 Kg |
| 40x40x1,20 mm | 1,46 Kg | 8,75 Kg |
| 40x40x1,50 mm | 1,87 Kg | 11,23 Kg |
| 40x40x2,00 mm | 2,49 Kg | 14,96 Kg |
| 40x40x2,50 mm | 3,12 Kg | 18,72 Kg |
| 40x40x3,00 mm | 3,74 Kg | 22,46 Kg |
| 40x40x4,00 mm | 4,99 Kg | 29,95 Kg |
| 40x60x1,20 mm | 1,84 Kg | 11,01 Kg |
| 40x60x1,50 mm | 2,34 Kg | 14,04 Kg |
| 40x60x2,00 mm | 3,12 Kg | 18,72 Kg |
| 40x60x2,50 mm | 3,90 Kg | 23,40 Kg |
| 40x60x3,00 mm | 4,68 Kg | 28,08 Kg |
| 40x60x4,00 mm | 6,24 Kg | 37,44 Kg |
| 40x60x5,00 mm | 7,80 Kg | 46,80 Kg |
| 40x80x1,50 mm | 2,81 Kg | 16,84 Kg |
| 40x80x2,00 mm | 3,74 Kg | 22,46 Kg |
| 40x80x2,50 mm | 4,68 Kg | 28,08 Kg |
| 40x80x3,00 mm | 5,62 Kg | 33,69 Kg |
| 40x80x4,00 mm | 7,49 Kg | 44,92 Kg |
| 40x100x1,50 mm | 3,28 Kg | 19,65 Kg |
| 40x100x2,00 mm | 4,37 Kg | 26,20 Kg |
| 40x100x2,50 mm | 5,46 Kg | 32,76 Kg |
| 40x100x3,00 mm | 6,55 Kg | 39,31 Kg |
| 40x100x4,00 mm | 8,74 Kg | 52,41 Kg |
| 40x100x6,00 mm | 12,03 Kg | 72,18 Kg |
| 50x50x1,20 mm | 1,84 Kg | 11,01 Kg |
| 50x50x1,50 mm | 2,34 Kg | 14,04 Kg |
| 50x50x2,00 mm | 3,12 Kg | 18,72 Kg |
| 50x50x2,50 mm | 3,90 Kg | 23,40 Kg |
| 50x50x3,00 mm | 4,68 Kg | 28,08 Kg |
| 50x90x1,50 mm | 3,28 Kg | 19,65 Kg |
| 50x90x2,00 mm | 4,37 Kg | 26,20 Kg |
| 50x90x2,50 mm | 5,46 Kg | 32,76 Kg |
| 50x90x3,00 mm | 6,55 Kg | 39,31 Kg |
| 50x90x4,00 mm | 8,74 Kg | 52,41 Kg |
| 50x90x6,00 mm | 12,03 Kg | 72,18 Kg |
| 50x100x1,50 mm | 3,51 Kg | 21,06 Kg |
| 50x100x2,00 mm | 4,68 Kg | 28,08 Kg |
| 50x100x2,50 mm | 5,68 Kg | 34,07 Kg |
| 50x100x3,00 mm | 7,02 Kg | 42,12 Kg |
| 50x100x4,00 mm | 9,36 Kg | 56,16 Kg |
| 50x100x6,00 mm | 12,97 Kg | 77,82 Kg |
| 50x150x2,00 mm | 6,24 Kg | 37,44 Kg |
| 50x150x2,50 mm | 7,64 Kg | 45,82 Kg |
| 50x150x3,00 mm | 9,36 Kg | 56,16 Kg |
| 50x150x4,00 mm | 12,48 Kg | 74,88 Kg |
| 60x60x1,50 mm | 2,81 Kg | 16,84 Kg |
| 60x60x2,00 mm | 3,74 Kg | 22,46 Kg |
| 60x60x2,50 mm | 4,68 Kg | 28,08 Kg |
| 60x60x3,00 mm | 5,62 Kg | 33,69 Kg |
| 60x60x4,00 mm | 7,49 Kg | 44,92 Kg |
| 60x80x1,50 mm | 3,28 Kg | 19,65 Kg |
| 60x80x2,00 mm | 4,37 Kg | 26,20 Kg |
| 60x80x2,50 mm | 5,46 Kg | 32,76 Kg |
| 60x80x3,00 mm | 6,55 Kg | 39,31 Kg |
| 60x80x4,00 mm | 8,74 Kg | 52,41 Kg |
| 60x80x6,00 mm | 12,03 Kg | 72,18 Kg |
| 60x100x2,00 mm | 4,99 Kg | 29,95 Kg |
| 60x100x2,50 mm | 6,24 Kg | 37,44 Kg |
| 60x100x3,00 mm | 7,49 Kg | 44,92 Kg |
| 60x100x4,00 mm | 9,36 Kg | 56,16 Kg |
| 60x100x5,00 mm | 12,48 Kg | 74,88 Kg |
| 60x100x6,00 mm | 13,91 Kg | 83,46 Kg |
| 60x120x2,00 mm | 5,62 Kg | 33,69 Kg |
| 60x120x2,50 mm | 7,02 Kg | 42,12 Kg |
| 60x120x3,00 mm | 8,42 Kg | 50,54 Kg |
| 60x120x4,00 mm | 11,23 Kg | 67,39 Kg |
| 60x120x6,00 mm | 15,79 Kg | 94,73 Kg |
| 70x70x1,50 mm | 3,28 Kg | 19,65 Kg |
| 70x70x2,00 mm | 4,37 Kg | 26,20 Kg |
| 70x70x2,50 mm | 5,46 Kg | 32,76 Kg |
| 70x70x3,00 mm | 6,55 Kg | 39,31 Kg |
| 70x70x4,00 mm | 8,74 Kg | 52,41 Kg |
| 70x70x6,00 mm | 12,03 Kg | 72,18 Kg |
| 80x80x2,00 mm | 4,99 Kg | 29,95 Kg |
| 80x80x2,50 mm | 6,24 Kg | 37,44 Kg |
| 80x80x3,00 mm | 7,49 Kg | 44,92 Kg |
| 80x80x4,00 mm | 9,98 Kg | 59,90 Kg |
| 80x80x6,00 mm | 13,91 Kg | 83,46 Kg |
| 80x100x2,00 mm | 5,62 Kg | 33,69 Kg |
| 80x100x2,50 mm | 7,02 Kg | 42,12 Kg |
| 80x100x3,00 mm | 8,42 Kg | 50,54 Kg |
| 80x100x4,00 mm | 11,23 Kg | 67,39 Kg |
| 80x100x5,00 mm | 14,04 Kg | 84,24 Kg |
| 80x100x6,00 mm | 15,79 Kg | 94,73 Kg |
| 80x120x2,00 mm | 6,24 Kg | 37,44 Kg |
| 80x120x2,50 mm | 7,80 Kg | 46,80 Kg |
| 80x120x3,00 mm | 9,36 Kg | 56,16 Kg |
| 80x120x4,00 mm | 12,48 Kg | 74,88 Kg |
| 80x120x6,00 mm | 17,67 Kg | 106,01 Kg |
| 80x120x8,00 mm | 23,06 Kg | 138,34 Kg |
| 80x140x2,50 mm | 8,42 Kg | 50,52 Kg |
| 80x140x3,00 mm | 10,06 Kg | 60,34 Kg |
| 80x140x4,00 mm | 13,28 Kg | 79,70 Kg |
| 80x140x6,00 mm | 19,55 Kg | 117,29 Kg |
| 80x140x8,00 mm | 25,56 Kg | 153,38 Kg |
| 80x160x3,00 mm | 11,23 Kg | 67,39 Kg |
| 80x160x4,00 mm | 14,99 Kg | 89,95 Kg |
| 80x160x5,00 mm | 18,72 Kg | 112,32 Kg |
| 80x160x6,00 mm | 21,43 Kg | 128,57 Kg |
| 80x160x8,00 mm | 28,07 Kg | 168,42 Kg |
| 90x90x2,00 mm | 5,62 Kg | 33,69 Kg |
| 90x90x2,50 mm | 7,02 Kg | 42,12 Kg |
| 90x90x3,00 mm | 8,42 Kg | 50,54 Kg |
| 90x90x4,00 mm | 11,23 Kg | 67,39 Kg |
| 90x90x5,00 mm | 14,04 Kg | 84,24 Kg |
| 90x90x6,00 mm | 15,79 Kg | 94,73 Kg |
| 100x100x2 mm | 6,24 Kg | 37,44 Kg |
| 100x100x2,5 mm | 7,80 Kg | 46,80 Kg |
| 100x100x3 mm | 9,36 Kg | 56,16 Kg |
| 100x100x4 mm | 12,48 Kg | 74,88 Kg |
| 100x100x5 mm | 15,60 Kg | 93,60 Kg |
| 100x100x6 mm | 17,67 Kg | 106,01 Kg |
| 100x100x8 mm | 23,01 Kg | 138,04 Kg |
| 100x120x2,5 mm | 8,42 Kg | 50,52 Kg |
| 100x120x3 mm | 10,06 Kg | 60,34 Kg |
| 100x120x4 mm | 13,28 Kg | 79,70 Kg |
| 100x120x6 mm | 19,55 Kg | 117,29 Kg |
| 100x120x8 mm | 25,56 Kg | 153,38 Kg |
| 100x150x3 mm | 11,70 Kg | 70,20 Kg |
| 100x150x4 mm | 15,60 Kg | 93,60 Kg |
| 100x150x5 mm | 19,50 Kg | 117,00 Kg |
| 100x150x6 mm | 22,37 Kg | 134,21 Kg |
| 100x150x8 mm | 29,32 Kg | 175,93 Kg |
| 100x200x3 mm | 14,04 Kg | 84,24 Kg |
| 100x200x4 mm | 18,72 Kg | 112,32 Kg |
| 100x200x5 mm | 23,40 Kg | 140,40 Kg |
| 100x200x6 mm | 27,07 Kg | 162,40 Kg |
| 100x200x8 mm | 35,59 Kg | 213,53 Kg |
| 110x110x2,5 mm | 8,42 Kg | 50,52 Kg |
| 110x110x3 mm | 10,06 Kg | 60,34 Kg |
| 110x110x4 mm | 13,28 Kg | 79,70 Kg |
| 110x110x6 mm | 19,55 Kg | 117,29 Kg |
| 110x110x8 mm | 25,56 Kg | 153,38 Kg |
| 120x120x3 mm | 11,23 Kg | 67,39 Kg |
| 120x120x4 mm | 14,99 Kg | 89,95 Kg |
| 120x120x5 mm | 18,72 Kg | 112,32 Kg |
| 120x120x6 mm | 21,43 Kg | 128,57 Kg |
| 120x120x8 mm | 28,07 Kg | 168,42 Kg |
| 140x140x3 mm | 12,88 Kg | 77,25 Kg |
| 140x140x4 mm | 17,04 Kg | 102,25 Kg |
| 140x140x5 mm | 21,15 Kg | 126,88 Kg |
| 140x140x6 mm | 25,19 Kg | 151,12 Kg |
| 140x140x8 mm | 33,08 Kg | 198,49 Kg |
| 140x140x10 mm | 40,73 Kg | 244,35 Kg |
| 150x150x3 mm | 14,04 Kg | 84,24 Kg |
| 150x150x4 mm | 18,72 Kg | 112,32 Kg |
| 150x150x5 mm | 23,40 Kg | 140,40 Kg |
| 150x150x6 mm | 27,07 Kg | 162,40 Kg |
| 150x150x8 mm | 35,59 Kg | 213,53 Kg |
| 150x200x3 mm | 16,17 Kg | 96,99 Kg |
| 150x200x4 mm | 21,43 Kg | 128,57 Kg |
| 150x200x5 mm | 26,63 Kg | 159,77 Kg |
| 150x200x6 mm | 31,77 Kg | 190,60 Kg |
| 150x200x8 mm | 41,85 Kg | 251,12 Kg |
| 150x250x4 mm | 24,96 Kg | 149,76 Kg |
| 150x250x5 mm | 27,30 Kg | 163,80 Kg |
| 150x250x6 mm | 36,47 Kg | 218,79 Kg |
| 150x250x8 mm | 48,12 Kg | 288,71 Kg |
| 150x250x10 mm | 59,52 Kg | 357,13 Kg |
| 175x175x3 mm | 16,17 Kg | 96,99 Kg |
| 175x175x4 mm | 21,43 Kg | 128,57 Kg |
| 175x175x5 mm | 26,63 Kg | 159,77 Kg |
| 175x175x6 mm | 31,77 Kg | 190,60 Kg |
| 175x175x8 mm | 41,85 Kg | 251,12 Kg |
| 200x200x4 mm | 24,56 Kg | 147,36 Kg |
| 200x200x5 mm | 30,54 Kg | 183,26 Kg |
| 200x200x6 mm | 36,47 Kg | 218,79 Kg |
| 200x200x8 mm | 48,12 Kg | 288,71 Kg |
| 200x200x10 mm | 59,52 Kg | 357,13 Kg |
| 200x300x5 mm | 39,00 Kg | 234,00 Kg |
| 200x300x6 mm | 45,86 Kg | 275,18 Kg |
| 200x300x8 mm | 60,65 Kg | 363,90 Kg |
| 200x300x10 mm | 75,19 Kg | 451,11 Kg |
| 250x250x5 mm | 39,00 Kg | 234,00 Kg |
| 250x250x6 mm | 45,86 Kg | 275,18 Kg |
| 250x250x8 mm | 60,65 Kg | 363,90 Kg |
| 250x250x10 mm | 75,19 Kg | 451,11 Kg |
For additional sizes or special requirements, please contact us to receive the full list of painted hollow section stock sizes and prices.
Coating Systems and Technical Specifications
Online Quote for Painted Hollow Sections
If you are looking to buy painted hollow sections online or request a project-specific offer, HL Metal can prepare a detailed quotation including technical specifications, coating types and logistics options. You can easily send us your enquiry and receive a customized painted hollow section online quote.
Get a Painted Hollow Section Price Offer from HL Metal
For direct contact or to send your steel list, please use our contact form:
Contact HL Metal – Painted Hollow Section QuoteAdvanced Hollow Section & Structural Profile Solutions
HL Metal supplies galvanized, stainless, cold rolled and custom-shaped hollow sections, supported by precision laser processing and light gauge steel manufacturing.
Galvanized Hollow Sections
High durability with zinc-coated protection for outdoor and industrial steel constructions.
Stainless Steel Hollow Sections
Premium 304 / 316 stainless steel profiles for architectural, hygienic and corrosive environments.
Cold Rolled Hollow Sections
Smooth surface, high precision and tight tolerances ideal for machinery & furniture production.
Special Shaped Profiles
Custom U, Z, Omega and project-specific profiles manufactured according to your drawings.
Laser Cutting Tube & Hollow Section
Precision laser processing for SHS, RHS and round tubes – holes, slots, mitre cuts and more.
Light Gauge Steel Profiles
High-strength lightweight profiles for prefabricated buildings, wall studs and roof structures.
Request a Combined Hollow Section Offer
Need SHS, RHS, galvanized, stainless or custom-shaped hollow sections together with laser cutting? Share your full list and receive a tailored quotation with competitive export pricing.
Pre-Painted Hollow Section, Anticorrosive Painted Hollow Section
Painted steel hollow sections are widely used in both structural and architectural applications due to their aesthetic appeal and enhanced corrosion resistance. Whether you’re looking for powder coated hollow sections for indoor frameworks or pre-painted hollow sections for outdoor durability, these profiles offer excellent versatility. HL Metal supplies a broad range of painted RHS and SHS profiles in multiple sizes and thicknesses to meet custom project requirements.
Our rectangular hollow sections painted with high-quality coatings provide a smooth and durable finish suitable for industrial, commercial, or decorative use. Similarly, square hollow sections painted in various RAL colors offer a clean, uniform appearance for visible steel structures.
For applications demanding both strength and style, painted structural steel tubes ensure reliable performance while also resisting environmental wear. These corrosion resistant hollow sections reduce the need for frequent maintenance, making them a cost-effective choice. Additionally, decorative steel box sections are often used in modern architectural projects requiring precise lines and consistent coloring.
HL Metal is proud to offer top-grade painted hollow profiles, delivering long-lasting performance with aesthetic flexibility tailored to your industry needs.
HL Metal Demir Çelik Sanayi offers painted hollow sections, coated steel hollow sections, and painted steel profiles designed for strength and corrosion resistance. Our corrosion-resistant hollow sections and HL Metal Demir Çelik painted sections meet industrial standards for durability. We supply industrial painted hollow sections and construction steel hollow sections for reliable performance. Our durable painted hollow profiles and structural painted hollow sections ensure long-lasting coated hollow steel solutions for a wide range of construction and industrial projects.
Steel Hollow Sections Prices, Aluminum Hollow Sections Price, Stainless Steel Hollow Section Prices, Hollow Sections Dimensions, Galvanized Hollow Sections Price, Hollow Sections Weight Chart, DKP (Cold Rolled) Steel Profile Prices, Painted Hollow Section Prices
