NPI Beams
NPI Beams (IPN Beams) – Dimensions, Weights, Technical Data and Export from Turkey
NPI beams (also known as IPN beams or European Standard Tapered Flange I-Beams) are narrow-flange structural steel sections designed for excellent load-bearing capacity, precise dimensional control and efficient material usage. Their compact profile and optimized cross-section make them ideal for space-constrained and cost-sensitive structural projects.
HL Metal Demir Çelik Sanayi supplies and exports NPI / IPN steel beams from IPN 80 to IPN 600, produced according to EN 10365 and EN 10025 in grades S235JR, S275JR and S355JR. We serve steel fabricators, construction companies and industrial buyers throughout Europe, the Middle East and North Africa as a reliable IPN beam supplier in Turkey.
For other structural profiles such as UPN channels, HEA beams, HEB beams, IPE sections and UPE sections, as well as hollow sections, you can visit our related product pages.
What Are NPI Beams (IPN Beams)?
NPI beams, also referred to as IPN beams or narrow parallel flange I-beams, are structural steel components with relatively narrow, tapered flanges and a high strength-to-weight ratio. The flanges run almost parallel to each other, while the web provides excellent resistance against bending and shear loads.
Produced under strict European standards, NPI steel profiles are widely used in construction, civil engineering, shipbuilding and industrial fabrication. They are preferred by engineers and architects who require IPN steel beams with high performance, predictable behaviour and efficient material use.
As a Turkish NPI beam supplier, HL Metal combines technical support, flexible production and export-oriented logistics for international projects.
If your design also includes U and H profiles, you can review our UPN profiles, HEA beam, HEB beam, IPE beam and UPE section pages.
Key Characteristics of NPI / IPN Beams
- High Load Capacity: Optimized cross-section allows IPN beams to handle significant vertical and horizontal loads.
- Dimensional Accuracy: Manufactured under tight tolerances for consistent dimensions and predictable structural performance.
- Material Efficiency: Narrow flange design uses less steel while maintaining strength, reducing overall project costs.
- Corrosion Resistance: When supplied as galvanized IPN beams or coated beams, they withstand aggressive environments.
- Customizable Dimensions: Available in a wide range of IPN sizes, thicknesses and steel grades to match different applications.
Main Applications of NPI / IPN Steel Profiles
NPI beams and IPN profiles play a vital role in many structural and mechanical applications:
- Building Construction: Floor systems, roof supports, secondary beams and frameworks for reliable load distribution and stability.
- Industrial Fabrication: Machine frames, heavy-duty equipment supports, conveyor and handling systems.
- Civil Engineering Projects: Bridges, tunnels, viaducts and infrastructure requiring high-strength IPN steel beams.
- Shipbuilding & Marine Structures: Ship frames and offshore modules where precision and corrosion resistance are essential.
- Architectural & Lightweight Structures: Modern architectural designs that benefit from compact, visually clean NPI sections.
For projects where NPI beams are used together with other profiles, HL Metal can prepare combined offers including: HEA beams, HEB beams, IPE beams, UPN channels, UPE sections and hollow sections.
Advantages of Using NPI / IPN Beams
- Superior Strength-to-Weight Ratio: Maximizes load capacity with less material, ideal for economical steel design.
- Design Flexibility: Suitable for both lightweight constructions and heavy-duty industrial applications.
- Ease of Fabrication: Perfect for welding, bolting, drilling and machining in workshop and on site.
- Lower Carbon Footprint: Efficient use of steel reduces embodied carbon compared to oversized sections.
- Extended Service Life: When combined with hot-dip galvanizing, priming or painting, IPN beams offer long-term durability.
Technical Specifications for NPI / IPN Beams
HL Metal supplies NPI steel profiles and IPN steel beams according to European standards with full traceability.
| Parameter | Details |
|---|---|
| Product Names | NPI beams, IPN beams, NPI steel profiles, IPN steel beams, European Standard Tapered Flange I-Beams, NPI sections |
| Standards | EN 10365 (hot rolled steel channels and beams), EN 10025 (S235JR / S275JR / S355JR), EN 10204 (certification) |
| Steel Grades | S235JR, S275JR, S355JR |
| Dimensions | IPN 80 to IPN 600 – different beam heights, flange widths and web thicknesses according to standard tables. |
| Lengths | Standard 6 m and 12 m; other lengths and cut-to-length IPN beams on request. |
| Surface Options | As-rolled black, shot-blasted and primed, hot-dip galvanized, epoxy-coated according to project specifications. |
| Certificates | EN 10204 3.1 or 2.2 Mill Test Certificates for each IPN beam bundle. |
Our engineering team can support you with section selection, load calculations and optimization of IPN beam sizes for your project.
NPI Beam Dimensions – IPN Sizes and Weights
Below you can find sample IPN beam sizes, dimensions and theoretical weights for 6-meter lengths. For full IPN section tables and weight-per-meter calculation, you may also use our steel weight calculator or contact our technical team.
Note: Weights are theoretical and given for 6 m standard lengths. Actual weights may vary according to production tolerances.
| IPN Size | IPN Dimensions (mm) | IPN Weight (6 m) |
|---|---|---|
| IPN 80 Beam | 80 × 42 × 3.90 | 35.70 kg |
| IPN 100 Beam | 100 × 50 × 4.50 | 49.92 kg |
| IPN 120 Beam | 120 × 58 × 5.10 | 67.20 kg |
| IPN 140 Beam | 140 × 66 × 5.70 | 86.40 kg |
| IPN 160 Beam | 160 × 74 × 6.30 | 107.40 kg |
| IPN 180 Beam | 180 × 82 × 6.90 | 131.40 kg |
| IPN 200 Beam | 200 × 90 × 7.50 | 157.80 kg |
| IPN 220 Beam | 220 × 98 × 8.10 | 186.60 kg |
| IPN 240 Beam | 240 × 106 × 8.70 | 217.20 kg |
| IPN 260 Beam | 260 × 113 × 9.40 | 251.40 kg |
| IPN 280 Beam | 280 × 119 × 10.40 | 288.00 kg |
| IPN 300 Beam | 300 × 125 × 10.80 | 325.20 kg |
| IPN 320 Beam | 320 × 131 × 11.50 | 366.60 kg |
| IPN 340 Beam | 340 × 137 × 12.20 | 408.60 kg |
| IPN 360 Beam | 360 × 143 × 13.00 | 457.20 kg |
| IPN 380 Beam | 380 × 149 × 13.70 | 504.00 kg |
| IPN 400 Beam | 400 × 155 × 14.40 | 555.40 kg |
| IPN 450 Beam | 450 × 170 × 16.20 | 690.00 kg |
| IPN 500 Beam | 500 × 185 × 18.00 | 846.00 kg |
| IPN 550 Beam | 550 × 200 × 19.00 | 996.00 kg |
| IPN 600 Beam | 600 × 215 × 21.60 | 1194.00 kg |
If you need IPN 200 weight per meter, IPN 300 section properties or complete IPN beam dimension tables, please send us your list and our team will prepare detailed technical documentation.
Sustainability and IPN Beams
Modern construction and manufacturing industries increasingly focus on sustainable solutions. NPI beams and IPN steel beams contribute to these goals by:
- Minimizing raw material usage thanks to their efficient design.
- Being 100% recyclable at the end of their service life.
- Supporting green building certifications and low-carbon concepts.
By choosing NPI / IPN sections, project owners benefit from high structural performance while contributing to more responsible resource use.
High-Quality NPI / IPN Steel Beams – Prices, Services and Export
IPN beams, also called European Standard Tapered Flange I-Beams, are widely used in structural engineering, industrial steel constructions and general fabrication works. Their narrow, tapered flanges provide efficient load distribution, reduced weight and excellent bending resistance, making them ideal for frames, platforms, walkways and lighter structural systems.
HL Metal supplies IPN beams from IPN 80 to IPN 600, produced according to EN 10365 in S235JR / S275JR / S355JR grades. All beams are hot rolled and can be delivered with cutting-to-length, drilling, shot blasting, priming or galvanizing according to your project requirements.
Every IPN steel beam is supplied with its Mill Test Certificate (EN 10204 3.1 or 2.2) and packed for export to ensure safe transportation. As a Turkish IPN beam exporter, HL Metal offers competitive prices, fast dispatch and reliable logistics for international customers.
We can also combine IPN beams with HEA beams, HEB beams, IPE sections, UPN profiles, UPE sections and hollow sections in a single shipment for maximum cost efficiency.
Request an IPN Beam Quotation
Please send us your required IPN sizes (for example IPN 200, IPN 300, IPN 400), steel grade, total tonnage and preferred delivery term (EXW, FCA Istanbul, FOB, CFR, CIF, DAP). Our team will prepare a tailor-made NPI / IPN beam price offer for your project.
Contact HL Metal – Ask for IPN Beam QuoteNPI Profile – Comprehensive Guide for Engineers, Buyers, and Fabricators
The NPI Profile—often referred to as a Structural NPI Profile, NPI Steel Profile or NPI Steel Channel—is a dependable channel-type section widely used in industrial projects, commercial buildings, and infrastructure works. As a leading NPI Steel Supplier, HL Metal supports EPC contractors, OEMs, and fabricators with flexible sourcing, cutting, packaging, and just-in-time deliveries. On this page, you can quickly review NPI Channel Sizes, NPI Profile Dimensions, and learn how to interpret an NPI Profile Weight Chart—then check today’s NPI Channel Price or Buy NPI Profile Online via our RFQ workflow.
What Is an NPI Channel?
An NPI is a symmetric channel section optimized for strength-to-weight efficiency and ease of fabrication. When engineers specify channels for purlins, lintels, bracing, walkways, or equipment frames, the NPI Channel provides a well-balanced option between stiffness and weight. The geometry allows straightforward bolting/welding to plates and beams, and the open shape simplifies routing of cables, pipes, and services during installation.
Compared with angle or flat bars, an NPI Section (also called NPI Steel Section) delivers better resistance to bending and torsion thanks to its web-flange configuration. For applications requiring beam/channel compatibility or hybrid frames with I/H beams, an NPI Steel Beam pairing (e.g., used as secondary members or edge restraints) is also common in industrial steelwork.
Standards, Grades, and Compliance
Each NPI Profile Standard defines dimensional tolerances, corner radii, straightness, and permissible deviations to ensure interchangeability and predictable performance. In international projects, engineers often reference recognized European material standards and CE conformity for structural steel. As part of our compliance package, we provide mill test certificates, traceability codes, and (when requested) welding procedure records and galvanizing certificates aligned to the project specification.
For region-specific requirements—fire protection, corrosion categories, or surface preparation—our team helps align the European NPI Channel specification with coating systems, galvanizing classes, and inspection test plans. If you are integrating NPI with other section families, you may also review our pages for related products such as IPN Profile, Steel Beams, and Steel Sections.
NPI Channel Sizes and Dimensional Logic
Choosing the right NPI Channel Sizes starts with understanding the forces acting on the member—span, load, deflection limits, and connection details. Manufacturers roll a range of heights and flange/web thickness combinations so you can match strength and economy. Our customer success team can share rolling availability, minimum order quantities for niche sizes, and lead times for urgent projects.
Key Dimensional Parameters
- Height (h): Governs bending capacity and deflection. Taller sections typically resist bending better but can be heavier.
- Flange Width (b): Influences lateral stability, bolt spacing, and plate connectivity.
- Web Thickness (tw) & Flange Thickness (tf): Impact shear, local buckling, and weldability considerations.
- Root Radius & Tolerances: Affect fit-up, nesting in frames, and drilling/slotting operations.
If you need a specific size matrix for engineering approval, contact us. We will provide a dimension sheet that maps common NPI Profile Dimensions to section properties (A, Ix, Iy, Wx, Wy) for preliminary sizing and connection design.
How to Read an NPI Profile Weight Chart
An NPI Profile Weight Chart summarizes the theoretical mass per meter (kg/m) and section properties for each size. Use it to estimate total tonnage, transport loads, and crane picks before finalizing your order. Because production tolerances and coatings affect net weight, we always reconcile theoretical and actual shipping tallies in your packing list and invoice for precise accounting.
Need a pre-filled spreadsheet for take-offs? Ask for our editable template. We can align the chart to your BIM model or drawings and highlight alternates if value engineering is possible.
Applications: NPI Profile for Construction
The NPI Profile for Construction is widely used in:
- Industrial platforms & walkways: Channels form stringers and frames for grating decks and service platforms.
- Building frames: Lintels, headers, and bracing members around door/window openings.
- Equipment skids: Robust but economical frames that accommodate bolting/welding of machinery and enclosures.
- Conveyors & lines: Side members and supports in material handling and process equipment.
- Architectural details: Parapets, trims, and cladding sub-frames where a neat open section is preferred.
For hybrid systems, channels work alongside hollow sections and I/H beams. Explore steel beams and other sections for companion members.
Fabrication, Processing, and Surface Options
We supply channels in mill lengths or cut-to-length with end preparation as requested. Our fabrication menu includes straight cutting, mitre cutting, drilling, slotted holes, cope cuts, and welding to plates or gussets. For corrosion control, choose shotblasting, shop primer, hot-dip galvanizing, or duplex paint systems matched to your environment (C2–C5).
- Cutting & Nesting: Optimized to minimize scrap and reduce your total cost per installed meter.
- Holes & Slots: CNC drilling/slotting according to your bolt schedule and tolerances.
- Welded Assemblies: Sub-frames, stiffeners, and plate additions delivered as ready-to-install kits.
- Marking & Traceability: Heat numbers and part IDs labeled for fast site sorting.
Comparison: NPI vs. UPN and Other Channels
While both NPI and UPN belong to the channel family, the selection depends on structural needs, connection philosophy, and availability. If your specification is open to alternates, we can benchmark sizes and properties across UPN Profiles and other rolled channels to maintain performance while optimizing cost and lead time. Our engineering team can assist with “equal stiffness” or “equal strength” substitutions and issue a concise comparison note for consultant review.
Sourcing: Supplier Network and Manufacturing
HL Metal operates as a solution-driven NPI Steel Supplier, working closely with each NPI Profile Manufacturer in our network to balance cost, quality, and schedule. This multi-mill strategy gives you optionality when one mill is at capacity, and it allows us to align rolling plans with your project milestones. For repeat programs, we can lock framework pricing and mill slots so you receive guaranteed production windows.
Commercials: Price, RFQs, and Ordering
Checking the latest NPI Channel Price typically begins with your cut list, surface requirements, and delivery address. Our quotations indicate unit and total prices, packing method, lead time, and documentation. If you prefer a digital procurement flow, you can also Buy NPI Profile Online via our guided RFQ form—submit drawings, QC checklists, and delivery constraints in one place for faster approvals.
Typical Information to Share with Your RFQ
- Target sizes & NPI Channel Profile lengths (mill or cut-to-length)
- Surface condition (as-rolled, blasted, primed, galvanized, painted)
- Connection details (holes, slots, end preps, welded plates)
- Bundling and labeling needs (area/phase/floor)
- Delivery terms (EXW, FCA, FOB, CFR/CIF, DDP) and timeline
- Required certificates and inspections (MTC, NDT, coating DFT reports)
Quality Assurance and Documentation
Our QA flow covers material identification, dimensional checks, coating thickness measurements (where applicable), and final packing inspection. Traceability from heat to bundle is maintained throughout. For site audits, we can provide WPS/PQR summaries and inspector credentials. If your project requires specific acceptance criteria (e.g., tighter tolerances or additional NDT), we will embed them in the ITP and report pack.
Logistics, Packing, and Delivery
We handle full-truck and LCL/LTL shipments with export-grade packing. To save crane time and avoid re-handling, we label bundles for the destination zone (building, elevation, or gridline) and add QR codes when requested. Small lots can be consolidated with other steel items to optimize freight. Our regional coverage includes Europe, MENA, and beyond, with customs documentation prepared in advance to accelerate clearance.
Frequently Asked Questions
1) Can I order mixed lengths and small lots?
Yes. We efficiently consolidate small orders. Share your cut list and bundling preferences (e.g., by phase, area, or floor) and we will plan the packing sequence accordingly. This approach reduces site handling and shortens installation time.
2) Can you provide bar-stock and short pieces?
Absolutely. If you need short members for bracing, curbs, or trims, we can supply NPI Channel Bar pieces cut to precise lengths, deburred, and labeled per your drawing index.
3) What if the specified size is unavailable?
We will propose a technically equivalent NPI Channel or compatible UPN size along with a quick comparison sheet. Upon your approval, we finalize the substitution and update all pack lists and ID labels accordingly.
4) Do you support rush deliveries?
Yes—subject to rolling capacity and current stock. Tell us your earliest need-by date and we will present the fastest route, including interim part-deliveries if required by your construction sequence.
Why HL Metal for NPI Channels?
- Technical clarity: We translate drawings and specifications into unambiguous purchase lines.
- Value engineering: We review NPI Profile Dimensions and propose cost-savvy alternates if permitted.
- Documentation discipline: From MTC to coating reports, your dossier is complete and audit-ready.
- Execution focus: We align production, inspection, and logistics to your site milestones.
- Digital convenience: You can Buy NPI Profile Online or place a classic RFQ—whichever suits your workflow.
Related Products & Knowledge Base
Explore more structural sections and companion products for your frame design: UPE Profile (Channels), HEA/HEB/IPE Steel Beams, Structural Steel Tubes. If you need help mapping mixed section families, our engineers can prepare a brief layout and connection note.
Get Today’s Price and Availability
Ready to move forward? Ask for the current NPI Channel Price with delivery to your site or port. Our quotation will include lead time, documentation, and packing details. As a global NPI Steel Supplier with a strong mill network, we coordinate closely with each NPI Profile Manufacturer to protect your schedule.
Summary: Your NPI Channel, Delivered Right
From design assistance to shipment, HL Metal ensures your NPI Channel Profile arrives ready for installation—with the correct dimensions, surface condition, and labeling. Whether your team prefers classic RFQs or a streamlined digital path to Buy NPI Profile Online, we’ll align with your process and provide full transparency at every step.
