Industrial Pipes
Industrial Pipes
Industrial pipes are essential structural components used in various industrial applications for transporting fluids such as liquids, gases, and steam. They are manufactured from a range of materials including steel, stainless steel, PVC, and polyethylene. Industrial pipes are available in various diameters and wall thicknesses, making them suitable for different pressure and flow requirements.
Industrial Pipes Size, Industrial Pipes Dimension
Industrial pipes are manufactured in outer diameters ranging from 13 mm to 219 mm and wall thicknesses from 0.50 mm to 8.00 mm. The standard length is 6 meters, but custom lengths and cutting services can be provided upon request.
Common steel grades used in production include S235JR, S275JR, and S355JR. These specifications make industrial pipes suitable for a wide range of structural and fluid transport applications.
Industrial Pipes Diameter, Industrial Pipes Weight, Industrial Pipes Price
Industrial Pipes Thickness | Industrial Pipes Weights |
| Ø13X1,50 MM | 2,58 KG |
| Ø16X1,50 MM | 3,24 KG |
| Ø17X2,00 MM | 4,43 KG |
| Ø17X2,50 MM | 5,07 KG |
| Ø18X1,50 MM | 3,66 KG |
| Ø19X1,50 MM | 3,90 KG |
| Ø21X1,50 MM | 4,38 KG |
| Ø21X2,00 MM | 5,61 KG |
| Ø21X2,50 MM | 6,96 KG |
| Ø22X1,50 MM | 4,54 KG |
| Ø22X2,00 MM | 5,91 KG |
| Ø25X1,50 MM | 5,21 KG |
| Ø25X2,00 MM | 6,79 KG |
| Ø25X2,50 MM | 8,34 KG |
| Ø27X1,50 MM | 5,64 KG |
| Ø27X2,00 MM | 7,38 KG |
| Ø27X2,50 MM | 9,00 KG |
| Ø27X3,00 MM | 10,62 KG |
| Ø28X1,50 MM | 5,88 KG |
| Ø28X2,00 MM | 7,68 KG |
| Ø32X1,50 MM | 6,78 KG |
| Ø32X2,00 MM | 8,88 KG |
| Ø32X2,50 MM | 10,92 KG |
| Ø32X3,00 MM | 12,90 KG |
| Ø34X1,50 MM | 7,14 KG |
| Ø34X2,00 MM | 9,36 KG |
| Ø34X2,50 MM | 11,52 KG |
| Ø34X3,00 MM | 13,62 KG |
| Ø34X4,00 MM | 17,58 KG |
| Ø42X1,50 MM | 9,00 KG |
| Ø42X2,00 MM | 11,82 KG |
| Ø42X2,50 MM | 14,64 KG |
| Ø42X3,00 MM | 17,34 KG |
| Ø42X4,00 MM | 22,50 KG |
| Ø45X1,50 MM | 9,66 KG |
| Ø45X2,00 MM | 12,72 KG |
| Ø45X2,50 MM | 15,72 KG |
| Ø45X3,00 MM | 18,66 KG |
| Ø48X1,50 MM | 10,38 KG |
| Ø48X2,00 MM | 13,68 KG |
| Ø48X2,50 MM | 16,92 KG |
| Ø48X3,00 MM | 20,10 KG |
| Ø48X4,00 MM | 26,22 KG |
| Ø48X5,00 MM | 32,04 KG |
| Ø51X1,50 MM | 10,98 KG |
| Ø51X2,00 MM | 14,52 KG |
| Ø51X2,50 MM | 17,94 KG |
| Ø51X3,00 MM | 24,60 KG |
| Ø51X4,00 MM | 27,84 KG |
| Ø60X1,50 MM | 13,02 KG |
| Ø60X2,00 MM | 17,22 KG |
| Ø60X2,50 MM | 21,36 KG |
| Ø60X3,00 MM | 25,44 KG |
| Ø60X4,00 MM | 33,30 KG |
| Ø60X5,00 MM | 40,92 KG |
| Ø76X1,50 MM | 16,56 KG |
| Ø76X2,00 MM | 21,90 KG |
| Ø76X2,50 MM | 27,18 KG |
| Ø76X3,00 MM | 32,40 KG |
| Ø76X4,00 MM | 42,60 KG |
| Ø76X5,00 MM | 52,50 KG |
| Ø89X1,50 MM | 19,38 KG |
| Ø89X2,00 MM | 25,74 KG |
| Ø89X2,50 MM | 31,98 KG |
| Ø89X3,00 MM | 38,10 KG |
| Ø89X4,00 MM | 50,22 KG |
| Ø89X5,00 MM | 61,80 KG |
| Ø89X6,00 MM | 72,60 KG |
| Ø102X2,00 MM | 29,46 KG |
| Ø102X2,50 MM | 36,66 KG |
| Ø102X3,00 MM | 43,74 KG |
| Ø102X4,00 MM | 57,78 KG |
| Ø102X5,00 MM | 71,40 KG |
| Ø102X6,00 MM | 84,60 KG |
| Ø114X2,00 MM | 33,24 KG |
| Ø114X2,50 MM | 41,34 KG |
| Ø114X3,00 MM | 49,38 KG |
| Ø114X4,00 MM | 65,40 KG |
| Ø114X5,00 MM | 81,00 KG |
| Ø114X6,00 MM | 96,00 KG |
| Ø127X2,50 MM | 46,08 KG |
| Ø127X3,00 MM | 55,02 KG |
| Ø127X4,00 MM | 72,60 KG |
| Ø127X5,00 MM | 90,00 KG |
| Ø127X6,00 MM | 107,40 KG |
| Ø127X8,00 MM | 141,00 KG |
| Ø139X2,50 MM | 50,76 KG |
| Ø139X3,00 MM | 60,60 KG |
| Ø139X4,00 MM | 80,40 KG |
| Ø139X5,00 MM | 99,60 KG |
| Ø139X6,00 MM | 118,80 KG |
| Ø139X8,00 MM | 156,00 KG |
| Ø168X3,00 MM | 73,08 KG |
| Ø168X4,00 MM | 96,85 KG |
| Ø168X5,00 MM | 120,32 KG |
| Ø168X6,00 MM | 143,50 KG |
| Ø168X8,00 MM | 188,97 KG |
| Ø219X3,00 MM | 95,66 KG |
| Ø219X4,00 MM | 126,96 KG |
| Ø219X5,00 MM | 157,96 KG |
| Ø219X6,00 MM | 188,67 KG |
| Ø219X8,00 MM | 249,20 KG |
Industrial Pipe Surface Finishing Options
Galvanized: Coated with hot-dip galvanizing to enhance corrosion resistance.
Painted: Can be painted in black, gray, or brick red using water-based paints.
Protective Oiled: Cold-rolled products are coated with protective oil during production.
Industrial pipes are indispensable components in industrial applications due to their durability and wide range of uses. They are manufactured in various materials and coatings depending on the application and requirements.
Applications of Industrial Pipes
Construction Industry: Used in structural applications, steel frameworks, and roofing systems.
Automotive Industry: Preferred in vehicle parts and automotive sub-industries.
Machinery Manufacturing: Applied in the production of machines and equipment.
Furniture Manufacturing: Utilized in the production of furniture and metal furnishings.
Agriculture: Commonly used in greenhouses and irrigation systems.
Other Applications: Also used in warehouse and store shelving systems, scaffolding, and formwork structures.
