HEM Beams

HEM Beams

HEM Beams (Heavy European Metric Beams) are steel profiles with a wide flange and exceptionally high load-bearing capacity. They are typically used in heavy industrial structures, long-span bridges, and buildings requiring maximum strength and rigidity.

Key Features of HEM Beams:

  • Extra-Wide Flanges: Provide exceptional resistance to bending and shear forces.

  • High Structural Performance: Ideal for load-intensive applications and areas exposed to dynamic stresses.

  • Precision Dimensions: Manufactured in accordance with EN 10365 and DIN 1025 standards.

  • Available Grades: Commonly produced in S235JR, S275JR, and S355JR steel grades for different strength requirements.

  • Size Range: Typically available from HEM 100 to HEM 1000, where the number represents the section height in millimeters.

HEM Beams Types, HEM Beams Weight, HEM Beams Dimensions


Weight (Kg/M)
Depth (mm)
Width (mm)
Web Thickness (mm)
Flange Thickness (mm)
Root Radius / Inner Radius (mm)
HEM 10041,8120106122012
HEM 12052,114012612,52112
HEM 14063,2160146132212
HEM 16076,2180166142315
HEM 18088,920018614,52415
HEM 200103220206152518
HEM 22011724022615,52618
HEM 240157270248183221
HEM 2601722902681832,524
HEM 28018931028818,53324
HEM 300238340310213927
HEM 320245359309214027
HEM 340248377309214027
HEM 360250395308214027
HEM 400256432307214027
HEM 450263478307214027
HEM 500270524306214027
HEM 550278572306214027
HEM 600285620305214027
HEM 650293668305214027
HEM 700301716304214027
HEM 800317814303214030
HEM 900333910302214030
HEM 10003491008302214030

Applications of HEM Beams:

  • Heavy Industrial Buildings

  • Long-Span Bridges

  • Power Plants and Energy Infrastructure

  • High-Load Crane Systems

  • Seismic-Resistant Structural Designs

Click here for HEM Beam Types, HEM Beam Weight, and HEM Beam Dimensions.

Applications of HEM Beams

Heavy Industrial Buildings, Long-Span Bridges, Power Plants and Energy Infrastructure, High-Load Crane Systems, Seismic-Resistant Structural Designs

HEM Beam Types, Weight, and Dimensions

  • HEM Beam Types:
    A standardized series of heavy-duty H-shaped steel beams, typically ranging from HEM 100 to HEM 1000, designed for maximum structural strength and load capacity.

  • HEM Beam Weight:
    Due to their extra-wide and thick flanges, HEM beams are heavier than HEA and HEB beams. The weight per meter depends on the beam size and steel grade. These beams are ideal for load-critical structural systems.

  • HEM Beam Dimensions:
    Manufactured in accordance with EN 10365 and DIN 1025, HEM beams feature large cross-sectional areas, high moment of inertia, and excellent bending resistance. The number (e.g., HEM 300) refers to the section height in millimeters.

Comparison with Other Structural Profiles

Profile TypeShapeFlange CharacteristicsLoad CapacityTypical Use Case
IPE BeamNarrow “I”-shapeThin, narrow flangesLight loadsLight structural elements
HEA BeamWide “H”-shapeThin, wide flangesMedium loadsGeneral structures
HEB BeamWide “H”-shapeThick, wide flangesHeavy loadsIndustrial & structural
HEM BeamExtra-wide “H”Extra thick and wide flangesExtremely heavy loadsHeavy-duty frameworks

Ordering HEM Beams

At HL Metal Demir Çelik Sanayi, we offer a wide range of standard-sized HEM beams and also provide custom fabrication to meet specific project needs. Whether you require large-volume supply or custom-cut sections, our experienced team is ready to support your project with fast delivery and competitive pricing.

Contact us today to request a detailed HEM beam price list or to place an order tailored to your specifications.
